S0504B000 Bathroom Exhaust Fan Motor Assembly

S0504B000 Bathroom Exhaust Fan Motor Assembly

Key Features

• Complete, pre-assembled unit includes motor, blower wheel, and mounting plate
• Airflow Rating: 70 CFM
• Electrical Rating: 120V, 1.0A
• Power Connector: 2-prong plug
• Cooling Method: Air-cooled

Replaces / Cross-Reference Part Numbers

• Broan / NuTone: S0504B000, 0504B000
• Motor Only: JESP-61K13, JESP-61K20, C-87547, S-87547000

Compatibility & Fitment

• Designed for Broan-NuTone ventilation fans
• Fits Models: 757, 763RLN, 765RL, 769RFT-R01, 769RL, 769RL-R01, VF707RCN

When to Replace

• Fan motor is humming, grinding, or making excessive noise
• Blower wheel is damaged or unbalanced
• Fan fails to turn on or spins too slowly
• Airflow is noticeably reduced

Installation Tips

• Disconnect power at the circuit breaker before beginning installation
• Confirm compatibility by checking the model number on your existing fan housing
• Clean the fan housing and duct of any dust or debris before installing the new assembly
• Ensure the blower wheel spins freely without obstruction after installation
